Weight & Size Chart
Mild Steel Joists (ISMB / IS 2062 / IS 808) Dimensions & Weight Table
Complete weight specifications table per meter and standard 6 meter length for Mild Steel Joists (MS Joist / ISMB Series).
Mild Steel Joists Size & Weight Chart (ISMB / IS 808)
All Standard ISMB Profiles| Joist Designation (Profile) | Depth of Joist (h) mm | Flange Width (b) mm | Web Thickness (t_w) mm | Flange Thickness (t_f) mm | Weight per Meter (kg/m) |
|---|---|---|---|---|---|
| ISMB 100 | 100 | 50 | 4.7 | 7.0 | 11.5 |
| ISMB 125 | 125 | 75 | 4.4 | 7.6 | 13.3 |
| ISMB 150 | 150 | 80 | 4.8 | 7.6 | 15.0 |
| ISMB 175 | 175 | 85 | 5.8 | 9.0 | 19.3 |
| ISMB 200 | 200 | 100 | 5.7 | 10.8 | 25.4 |
| ISMB 225 | 225 | 110 | 6.5 | 11.8 | 31.2 |
| ISMB 250 | 250 | 125 | 6.9 | 12.5 | 37.3 |
| ISMB 300 | 300 | 140 | 7.7 | 13.1 | 44.2 |
| ISMB 350 | 350 | 140 | 8.1 | 14.2 | 52.4 |
| ISMB 400 | 400 | 140 | 8.9 | 16.0 | 61.6 |
| ISMB 450 | 450 | 150 | 9.4 | 17.4 | 72.4 |
| ISMB 500 | 500 | 180 | 10.2 | 17.2 | 86.9 |
| ISMB 550 | 550 | 190 | 11.2 | 19.3 | 103.7 |
| ISMB 600 | 600 | 210 | 12.0 | 20.8 | 122.6 |
